RBF Morph took part at the second edition of the Geometry and Mesh Generation Workshop which will be held in San Diego January 5 and 6 2019. GMGW assess the current state-of-the art in geometry and mesh generation technology and software as applied to aircraft and spacecraft systems. We will present, in collaboration with ANSYS, a sophisticated geometric parameterization methodology based on RBF mesh morphing of a complete aircraft. A mesh generated on the OPAM model (Open Parametric Aircraft Model), provided by the organizing committee, was made parametric in the fuselage width, wing sweep, spanwise engine position and pod size.
Click here to download the presentation.
